The new Kit 149 software (V250303) also fixed some bugs in the previous V030303 release. Then all 3 kits will now be operating on the same clock speed and the user interface will be the same for all three kits. March 24 a new software package for Kit 149 is released with a hardware change needed: replace the 4.000MHz crystal by a 6.000MHz crystal. Originally there were going to be software packages for all three but it became clear that the one software package covering all three kit would be best. We are rapidly developing three new PIC programmers using the USB port: kits 128 149 and 150. New USB PIC Programmers - Design Philosophy Kits 149 128 & 150 This program corrects the Hex file so MicroPro can take it.
MicroPro rejects the file, and people can't use DIY Programmers as a result. Installation guides (PDFs) can be found at įixhex is a correction program for people that have C compilers that output odd number of bytes on a Hex file line. All the programmer kits use the 'FT232BM' chip.
Diy usb pic programmer zip file#
Select the driver for the Windows version you are using and the ZIP file will be downloaded.
Diy usb pic programmer drivers#
The USB VCP Windows drivers can be downloaded from the FTDI website at. You can download Bob's versions here - diypack22a.zip and diypack25a.zip This is a subtle hint that, like DOS, Microsoft is slowly dropping Win16 apps! So at the next release and thereafter, DIYPACKs will use the Win32 Installer. NOTHING is changed except the handler itself.
Diy usb pic programmer install#
So for people that were completely unable to install MicroPro, Bob has come up with different versions of DIYPACK22 and DIYPACK25. Bob has done some research and discovered that the handler was Win16 (1997). SOME versions of Windows XP won't allow the DIYPACK installer to work. Some users have experienced trouble installing Micropro. To load into 628A chips go into Fuses and turn all code protection OFF.
After you get the kit going then upgrade to the latest version by programming the firmware with the appropriate hex file from the latest version, replacing the firmware IC then running the latest MicroPro.exe.ĭiypack23v2.zip September 29, 2004. then you MUST get that version so that the supplied firmware runs with the MicroPro.exe version in the corresponding diypack.
If your kit documentation says to get diypack18 or diypack19 or diypack22 etc. Note 10K resistor needs to be added between pins 9 & 10 K128 and K182 are flash programmers and support only those PICs with an 'F' in the partnumber: Here is a list of the PICs the software & firmware of diypack25 supports for K149 and K150. Software protocol so people can port it to other platforms - click here (P018 as of August 16, 2004). No new PICs will be added for the time being. In Kit 149we are now using 3xBC327-40 instead of the BC558, and the SOT23 MMBT2907A transistor for the other kits.ĭownload diypack25.zip This will be the last diypack until P19/MP2 is released. One small problem we are fixing now is the transistors blowing particularly if ICSP wires are shortcircuited. If you log onto the Kit Forum you will see Bob Axtell is hard at work redesigning MicroPro, and doing a new PIC ProgrammerKit 185.
Diy usb pic programmer pdf#
See pdf files within each diypack for more information and schematics. Latest DIYpack for PIC programmers K128, K149, K150, K182īob has put together some Notes on PIC ICSP Programming.Ĭurrent Documentation being shipped with Kits 128 149 150 and 182.
